Click to zoomBrand: Dell
SKU: 285
Model: PowerEdge R760xs
Warranty: 1 Year repair or replace Warranty
2% OFF
The Dell PowerEdge R760xs is a scalable enterprise rack server designed for demanding business applications, virtualization, database workloads and professional IT infrastructure. This configuration features an Intel Xeon Silver 4514Y processor running at 2.0GHz with 16 cores and a 150W TDP. It includes 128GB dual-rank RDIMM operating at 5600MT/s, with support for up to 16 DIMMs as specified. Storage is provided by two 960GB SATA SSDs for 1.92TB of total raw capacity, managed through a PERC H755 SAS Front Storage Controller. Network connectivity is provided by a Broadcom 5720 Dual Port 1Gb On-Board LOM, while iDRAC9 Enterprise 16G supports remote server management. The system includes dual hot-plug redundant 700W MM HLAC Titanium power supplies and requires 200-240V input.
Intel Xeon Silver 4514Y; 2.0GHz processor; 16 cores; 150W TDP; 128GB RDIMM; 5600MT/s; Dual Rank memory; 16 DIMM maximum as specified; 2x 960GB SATA SSD; 1.92TB total raw SSD capacity; PERC H755 SAS Front Storage Controller; Broadcom 5720 Dual Port 1Gb On-Board LOM; iDRAC9 Enterprise 16G; dual hot-plug redundant 700W MM HLAC Titanium power supplies; 200-240V input
High-capacity memory configuration for demanding business workloads; 16-core Xeon processing for enterprise applications; fast SSD-based storage; hardware storage management through PERC H755; dual-port 1GbE connectivity; iDRAC9 Enterprise remote management; redundant hot-plug power supplies for improved infrastructure resilience; suitable for virtualization, databases, business applications, file services and commercial data-center deployments
The Dell PowerEdge R760xs is an enterprise rack server designed for organizations requiring dependable computing performance, high-capacity memory, fast SSD storage and professional remote management. This configuration is suitable for business applications, virtualization, databases, file services and commercial IT infrastructure.
The server is powered by an Intel Xeon Silver 4514Y processor with a 2.0GHz frequency, 16 cores and a 150W processor design. The multi-core architecture provides a strong foundation for demanding business and enterprise workloads.
This PowerEdge R760xs configuration includes 128GB RDIMM operating at 5600MT/s. The dual-rank memory configuration provides a high-capacity memory platform for applications requiring substantial system memory. The supplied configuration specifies support for up to 16 DIMMs.
Storage consists of 2x 960GB SATA SSDs, providing 1.92TB of total raw SSD capacity. The SSD configuration provides responsive storage for supported applications, databases and business data workloads.
A PERC H755 SAS Front Storage Controller provides dedicated storage-management capabilities for the server's supported storage configuration.
The integrated Broadcom 5720 Dual Port 1Gb On-Board LOM provides network connectivity for integration with business networks, server infrastructure and data-center environments.
iDRAC9 Enterprise 16G provides remote server management capabilities, helping IT administrators monitor and manage the PowerEdge R760xs as part of their infrastructure operations.
The server includes dual hot-plug redundant 1+1 700W MM HLAC Titanium power supplies. The supplied configuration is designed for 200-240V input only and is not intended for 100-120V outlets.
Looking for a Dell PowerEdge R760xs server in Dubai or the UAE? Contact Marvis Digital for availability, commercial pricing and server procurement support for business, enterprise and IT infrastructure requirements.
| Brand Dell | Servers Type |
| Input Frequency | Battery Type |
| Communication & Management Interface Port(s): Broadcom 5720 Dual Port 1Gb On-Board LOM | Dimensions And Weight Weight(imperial): Weight(metric): Product Dimensions (imperial): Product Dimensions (metric): |
